Production
-approximately 150 p/h with 5 litre single-cylinder doser
-approximately 300 p/h with 5 litre twin-cylinder
-doser approximately 120 p/h for 5 litre single-cylinder doser with bottom filling
-approximately 240 p/h 5 litre twin-cylinder doser with bottom filling
Free air consumption in liters per minute
-70 l/m for the single-cylinder version;
-140 l/m for the twin-cylinder version
Pneumatic power supply
Dimensions
-490 x 490 x 1441 mm H (single-cylinder version)
-610 x 490 x 1441 mm h (twin-cylinder version)
Weight
-70 kg (twin-cylinder version)
-50 kg (single-cylinder version)
Operating pressure
-6 bar

Available models
-Single cylinder with ranges from 100 to 2000 ml
-Twin cylinder with range from 100 to 2000 ml
-Single cylinder with range from 200 to 5000 ml
-Twin cylinder with range from 200 to 5000 ml
-Single cylinder with 316L stainless steel piston
-Twin cylinder with 316L stainless steel pistons
-Single cylinder with non-drip valves (1/2″ or 1/2″)
-Twin cylinder with non-drip valves (1/2″ or 1″)
-Single cylinder with plunger nozzles
-Twin cylinder with plunger nozzles
-Single cylinder with PVC valves
-Twin cylinder with PVC valves
Positioning
-on a trolley with wheels
Available dispensing nozzles
-Dispensing nozzle 1″ ø4
-Dispensing nozzle 1″ ø8
-Dispensing nozzle 1″ ø10
-Dispensing nozzle 1″ ø14
-Dispensing nozzle 1″ ø16
-Dispensing nozzle 1″ ø20
-Dispensing nozzle 1″ ø25
Available anti-drip valves
-2-way vertical valve 1” 14 – 8 mm
-2-way vertical valve 1” 18 – 10 mm
-2-way vertical valve 1” 21 – 13 mm
-2-way vertical valve 1” 25 – 15 mm
-2-way vertical valve 1/2” 5 – 3 mm
-2-way vertical valve 1/2” 7 – 5 mm
-2-way vertical valve 1/2” 10 – 7 mm
-2-way vertical valve 1/2” 17 – 12 mm
Gasket kits available
-in Silicone and PTFE
